Why Choose Our 15 Inch Industrial Touch Screen Monitor
Our 15 Inch Industrial Touch Screen Monitor is built for long hours of work in demanding spaces like factory floors, equipment stations, and industrial kiosks across Europe. It offers a responsive capacitive touch screen, high-clarity visuals, and strong IP65 front protection for safe use in dusty or wet areas common in German and Dutch production facilities.
ZL15TMBCAP has a tough metal housing, anti-glare tempered glass, and wide-angle viewing, making it perfect for smart manufacturing in Italy, Poland, and beyond. With easy VESA mounting and multiple input ports, it fits smoothly into HMI systems and industrial control cabinets. Plus, our European support center is ready to assist you quickly when needed. BaoBao Technology also offers a 15.6 inch industrial touchscreen monitor.
Display Characteristics
| Screen Diagonal (Inch/cm) | 15/38.14 |
| Aspect ratio | 4:3 |
| Brightness | 300 (cd/m2) |
| Contrast | 700:1 |
| Physical resolution | 1024x768 |
| Reaction Time (Tr/Tf) | 8/12 |
| LED Backlight Lifetime | 30000 (hours) |
| Visual Angle | 160 (H)/160 (V) |
Touch Panel
| Touch Technology | Projected Capacitive 10-point Multitouch |
| Touch Panel Drivers | Windows; Linux; Mac; Android |
| Touch Life (Contacts) | Unlimited |
| Surface Hardness | 7H |
| Surface Treatment | Anti-glare（optional） |
| Glass Strengthening | Tempered glass in 15 Inch Industrial Touch Screen Monitor |
Operation/Mechanical
| Operating Temperature (°C) | -10~+60 |
| Humidity Range (RH) | 10%-90% |
| Net Weight(Kg) | 4.10 |
| Gross Weight(Kg) | 5.10 (Incl.cartonage) |
| Housing Material | Aluminum front/back case |
| Housing(mm)L x W x H | 354.93 × 278.93 × 46.50 |
| Mounting | VESA 100 |
Power
| Power Indicator | Green LED |
| Power Supply | 12V 4.0A |
| Working Power (V) | 12 |
| Working Power (w) | 15 |
| Stand-By Consumption | <1 |
External Connectors
| Video | 1×HDMI 1.3 (Incl.HDCP) 1 × DVI-D 1 × VGA |
| Audio | 1×PC-Audio |
| Touch Connector | 1×USB |
| Connectors | 1×12V DC-IN |
| Ordering information | 15" Industrial Touch Screen Monitor |
IP Rating
| IP Rating | IP65 Front / IP40 Back |
Included in the delivery
| Power Adapter |
| HDMI |
| USB Touch |
| Power Cable |
