Features
High-Performance
Barcode
Fanless
Wireless
Multi Touch
IP65
RFID
OS
Durable Touchscreens
HDMI
Reasons to Choose Our 21.5 Inch Industrial Panel PC
Take your business activity to new heights with our 21.5″ pc industrial touch screen. We use a durable touchscreen with a high-resolution display that offers 500 cd/m² brightness, which helps run the working activity more efficiently and shows bright and clear images.
Our 10-point multi-touch screen comes with tempered glass that not only offers a responsive touch experience but also makes it impact and scratches-free. On the other hand, an IP65 front rating and aluminum frame make it an ideal choice for industry environments. BaoBao Technology also offers a 24″ industrial touchscreen panel pc.
Details Specifications
Display Characteristics
| Screen Diagonal (Inch/cm) | 21.5/54.69 |
| Aspect ratio | 16:9 |
| Brightness (cd/m²) | 500 |
| Contrast | 1000:1 |
| Physical resolution | 1920x1080 |
| Reaction Time (Tr/ Tf) | 1.5/3.5 |
| LED Backlight Lifetime (hours) | 40,000 |
| Visual Angle | 170 (H)/160 (V) |
Touch Panel
| Touch Technology | Projected Capacitive 10-point Multitouch |
| Touch Panel Drivers | Windows |
| Touch Life (Contacts) | Unlimited |
| Surface Hardness | 7H |
| Surface Treatment | Anti-glare（optional） |
IP Rating
| IP Rating | IP65 Front / IP40 Back |
Operation/Mechanical
| Operating Temperature | -10~+60 |
| Humidity Range (RH) | 10%-90% |
| Net Weight(Kg) | 6.7 |
| Gross Weight(Kg) | 7.9 ( Incl .ca rtonage) |
| Housing(mm)L x W x H | 517.44 X 313.31 X 55.58 |
| Mounting | VESA 100 |
| Housing Material | Aluminum Case |
Power
| Power Indicator | Green LED |
| Power Supply | 100-240V ACDC Active Switching; 12V DC-Out |
| Working Power (V) | 12 |
| Working Power (w) | 24 |
| Stand-By Consumption | <1 |
PC System
| CPU | Intel® Celeron® J6412 Processor |
| Chipset | Intel® NM70 express chipset |
| Graphic/GPU | Intel® Graphics 4000 |
| Memory | 8GB DDR3L non-ECC |
| Storage | 128GB SSD |
| Network | 2 x Realtek PCIe GB LAN 8111G; W-LAN |
Included in the delivery
| Power Adapter |
| HDMI |
| USB Touch |
| Power Cable |
