Model No: ZL215TMBCAP-OF
Capacitive Touch
Flat Design
1080P
10 Points
VESA
Anti-Glare (Optional)
At market-competitive prices, BaoBao Technology offers a high-performance 21.5 inch open frame touch screen monitor that has 10-point capacitive touch, and an attractive 1929×1080 high-resolution and flat design. While a 21.5″ size will give you an amazing and wide visual angle of 178° and an LED backlight with a lifetime of 100,000 hours. BaoBao Technology also offers a 27 Inch Open Frame Touch Screen Monitor.
Screen Diagonal (Inch/cm)
21.5/54.69
Aspect ratio
16:9
Brightness
350 (cd/m²)
Contrast
1000:1
Physical resolution
1920x1080
Typical Reaction Time Tr/ Tf (ms)
7/7
Visual Angle Horizontal / Verticle
178/178
LED Backlight Lifetime
100,000 (Hours)
Touch Technology
Projected Capacitive 10-point Multitouch
Touch Panel Drivers
Windows; Linux; Mac; Android
Touch Life (Contacts)
Unlimited
Surface Hardness
7H
Glass Strengthening
Tempered glass
Operating Temperature (°C)
-10 - +60
Humidity Range (RH)
10%-90%
Net Weight(Kg)
5.00
Gross Weight(Kg)
7.30 (incl. cartonage)
Housing Material
Aluminum
Housing(mm)L x W x H
527.9 X 328.0 X 51.1
Mounting
VESA 100
Power Indicator
Green LED
Power Supply
100-240V ACDC active switching;12V DC-Out
Working Power (V)
12
Working Power (w)
28
Stand-By Consumption
<1
Video
1x HDMI 1.3 (incl. HDCP) 1x DVI-D 1x VGA
Audio
1x PC-Audio
Touch Connector
1x USB
Connectors
250
Contrast
1x Serial 1x 12V DC-In
IP Rating
IP65 Front / IP40 Back
Power Adapter
HDMI
USB Touch
Power Cable
